Rugged Storage Systems
Reliable, rugged and secure - even in the harshest environments
Newly-developed Crystal Rugged Storage Systems offer high-reliability, ruggedness, and military grade data security in multiple form factors, without sacrificing performance or critical data.
This line of rugged storage products showcases the performance and mass storage capacity that can be unleashed from high bandwidth SAS architecture and high capacity enterprise-grade SATA hard drives or SSDs.
Most product configurations have been tested, please see the documents tab under more information to download product specific documentation.
Please contact us for a quote or to request more information.
RSS639 JBOD Rugged 6U Storage System
- Form Factor:
- 6U
- Overall Depth:
- 20.125"
- Hard Drives
- 39
- Storage Capacity:
- Up to 78TB
- I/O Position:
- Rear
- Stackable:
- Yes
- Weight:
- 160-175
- Power Supply Options:
- 120/240VAC 1350W N+1 W/PFC
Notes:
Rear I/O: Four (4) SFF-8088 SAS connections – two (2) for input, two (2) for output to enable daisy-chained units
When paired with a Crystal RS series RAID head unit, these storage systems can be operated in following RAID modes: 50, 60, JBOD or multiple arrays of 1, 1E, 5, 5EE, 6 or 10.
