ID1117/ID1117-4 Rugged Display

Keep a clear line of sight in extreme conditions. Partnering with Daisy Displays, we’ve engineered an industrial, high-performance 1U drawer display that meets the tactical needs for high brightness and contrast. The ID1117 and ID1117-4 provide big capabilities in compact, rugged, and versatile packages. The unique folding design provides a 17.3” LCD in a user-centric attitude for ease of use in critical land, air, and sea applications across the most demanding edge environments.

ID1117/ID1117-4 Rugged Display
  • 17.3” WUXGA LCD with 400 nit LED backlight
  • 1920 x 1080 resolution
  • On-screen display function
  • HulaPoint with USB keyboard
  • Optional four-port KVM switch
  • Heavy-duty NEMA 12 design
  • Easy, rack-mount 1U drawer
  • Auto-switching 120/240VAC power supply
  • Five-year warranty


Environmental Standards
MIL-STD-810, Operational Temperature -20°C to +50°C
Non-operational temperature -20°C to +60°C
MIL-STD-810, Humidity, Method 507, Procedure II 10% to 90%, non-condensing
Electromagnetic Compatibility Standards
CE/FCC Part 15, Class A, EN 60950 safety
Form factor 1U
Height 1.75" max (4.45 cm)
Width 18.9" (48.0 cm)
Depth 20.0" (50.8 cm)
Weight 20-22 lbs (9.0-9.9 kg)
Resolution 1920 x 1080 WUXGA
Active area 17.3" diagonal
Color palette 16.2 M colors (6-bit with FRC)
Aspect ratio 16:9
Viewing angle 85° x 85°
Brightness 400 nits
Power Supply
Auto switching 120/240 VAC 50/60Hz
65W (typical)
HulaPoint sealed, elastomeric USB keyboard
Mean Time Between Failures (MTBF)
70,000 hours at 40°C
Keyboard, Video, Mouse (KVM)
Four-port DVI and USB switch
Download Spec Sheet
