Field tested, fail-safe and long-life performance in extreme conditions. Crystal Group’s industrial servers are designed for demanding applications that require high-performance computing and high-capacity data storage. Constructed with rugged, all-aluminum chassis and state-of-the-art thermal management, these powerful, compact servers deliver seamless performance in the most harsh, unpredictable environments. In addition, these industrial servers meet strict environmental emission standards for an eco-friendly solution.
IS1200 Industrial Server
- Lightweight aluminum construction– 15 – 19 lbs.
- Easily mounted on ball bearing slides
- Up to 128GB of memory
- Industrial 1U, 13” depth
- Intel® Atom C3758 processor
- Modular design allows for easy reconfiguration and versatility
Environmental Standards
| Operational Temperature | -10°C to +50°C |
| Temperature Storage | -30°C to +75°C |
| Humidity (with optional kit) | 48 hrs, 5-95% RH 25-65C |
| Vibration | 5-2000Hz, 1.5GRMS, 75 minutes per axis |
| Shock | 20g, 11msec, 3 shocks each axes, each direction |
Electromagnetic Compatibility Standards
| FCC Class A |
Mechanical
| Form factor | 1U |
| Height | 1.75” (4.45 cm) |
| Width | 16.93” (44.45 cm) EIA-310 rack compliant |
| Depth | 13" (33.02 cm) |
| Weight | 15 - 19 lbs. (6.8 - 8.6 kg) |
Power Supply
| 300W |
CPU
| Intel® Atom C3758 | |
| Eight cores at 2.2GHz |
Expansion Slots
| One full-height, 3/4-length slot |
Memory
| 8-128GB, ECC, DDR4 |
Mounting
| EIA rack-mounted, ball bearing slides |
Cooling
| Redundant high-speed, high-volume fans; CPU temperature controlled |
System Board
| Advantech ASMB-260, single Intel Atom C3758, 1x LAN, 1x RS232, 1x VGA, 2x USB |
Software Compatibility
| Supports Windows 10®, Windows Server, VMware®, or Linux® |
