The Crystal Group FG2 1100 Series servers provide enhanced storage and CPU options based on specific application needs. Intel’s® latest Xeon® Scalable processors have built-in artificial intelligence (AI) acceleration with Intel® Deep Learning Boost, advanced encryption standard (AES), total memory encryption, software guard extensions (SGX), support a single- or dual-socket P+ FG2 motherboard, and increase system memory bandwidth with up to eight 3200MHz DDR4 channels.
Crystal Group FG2 1100 Series: 1U servers
- Single or dual processors
- 24 cores
- 1 PCIe
- Modular design
- AC or DC power
- 4TB RDIMM
Environmental Standards
| MIL-STD-810, Operational Temperature, high | Procedure II: +55°C, two-hour dwell, four cycles |
| MIL-STD-810, Operational Temperature, low | Procedure II: -40°C, two-hour dwell, four cycles |
| MIL-STD-810, Altitude, Method 500 | 12,500 ft. operation, 40,000 ft. transport |
| MIL-STD-810, Thermal Shock, Method 503 | Procedure II: 10 cycles, -40°C to +55°C, 15-min dwell, <1-min transfer time |
| MIL-STD-810, Humidity, Method 507 | Procedure II: 240 hours with optional conformal coating kit |
| MIL-STD-810, Fungus, Method 508 | 28 days, mixed spore, 30°C 95% RH |
| MIL-STD-810, Salt fog, Method 509 | 48-hour test |
| MIL-STD-810, Sand-Dust, Method 510 | Procedure I: Blasting dust, 12 hours |
| MIL-STD-810, Acceleration, Method 513 | Procedure II: 9g |
| MIL-STD-810, Vibration, Method 514 | Procedure I: 4.7G, 5–2,000Hz, 60 min/axis, 3 axis |
| MIL-STD-810, Shock, Method 516 | Procedures I & V: 40G, 11ms, 18 pulses, 3/axis both directions |
| MIL-STD-1474E, Acoustic Noise | Requirement S, Grade A3 |
| MIL-STD-167-1A, Ship Vibration | Type 1 |
| MIL-S-901E, Shipboard Shock | Class II, A/B |
Electromagnetic Compatibility Standards
| MIL-STD-461 | EMI/EMC, RE102, CE102; surface ship, below deck, and ground |
| RTCA/DO-160 | Aircraft and airborne equipment, Category M |
Mechanical
| Form Factor | 1U |
| Height | 1.75” (4.45 cm) |
| Depth | 19” (48.3 cm) or 22” (55.9 cm) |
| Width | 16.9” (44.5 cm) |
| Weight | 23–26 lbs (10.4-11.8 kg) or 26–29 lbs (11.8-13.2 kg) |
CPU
| Gen3 Intel Xeon Scalable or AMD EPYC 7003 series processors | |
| CPU Power: up to 165W per socket |
Expansion Slots
| One low-profile or full-height PCIe slot (motherboard dependent) |
External Bays
| Option 1 | Up to four bays populated with FORCE module accessories |
| Option 2 | Optical drive with up to two bays populated with FORCE module accessories |
Memory
| 16GB–4TB DDR4 ECC RDIMM/LRDIMM (motherboard dependent) |
Mounting
| Glides, fixed mount (front and rear), or Jonathan rails |
Power Supply
| 800WAC, 505W 18–36VDC |
Software Compatibility
| Windows 10, Windows Server, VMware, Linux, RedHat |
